Overview

The MSHG-120H is a video signal transmission device that departs from conventional cable-based connections,

allowing it to be mounted directly onto display equipment without the need for a separate cable.



Its compact, lightweight design offers excellent portability and easy installation, making it simple to use even in environments requiring frequent relocation.

It provides an efficient and reliable signal transmission environment across a wide range of on-site settings.



Product Features

  • Max 4K@60Hz output
  • Portable video signal generator
  • Easy function switching (rear button control)
  • Universal USB Type-B Micro (Micro 5-pin) power connector

Specification

SPECIFICATIONS
Product Name MSHG-120H
Resolution Up to UHD 3840 x 2160@60Hz
HDCP 1.4Ver, 2.2Ver Supported
Pixel Encoding RGB4:4:4, YCbCr4:4:4, YCbCr4:2:2
Power USB type B Micro (Micro 5pin) DC +5V / 0.9A (without battery)
Remarks HDCP, EDID, CEC Check function
Dimensions (W x D x H) 160 x 33 x 20 (mm)
Weight 80g
Operating Environment Temperature 0℃ ~40℃
Humidity Up to 80% RH (Non-Condensing)
Specifications and design are subject to change without prior notice.
